Harmar's all new Commercial Vertical Platform Lifts are manufactured to meet or exceed the most current safety design standards and have been ETL Listed.



The CPL series was designed with precision and care to be an incredibly high-quality, code compliant access solution. With heights available from 4’ to 14’, Harmar’s Highlander series is sure to meet your every need.



As with all Harmar lifts, the CPL is simpler to install, easy to operate and virtually maintenance free for use indoors and out.

Commercial Wheelchair Elevator Lift Features:

• Motor and electrical box both located at the top of the tower to eliminate water issues, and allow service without getting inside the tower
• Ability to unbolt the base to get the lift through small openings
• ETL Listed
• Available in AC and DC models
• Solid platform with non-skid surface for added safety
• Solid 42” high guard panels
• Weather-resistant design for indoor and outdoor use
• Constant pressure, paddle switch controls with emergency stop button
• Sensitive safety pan on bottom of platform stops the lift if it meets an obstruction
• Stationary access ramp
• Made in USA

Commercial Wheelchair Elevator Lift Documents:

• Manual(2.22 MB)
• Brochure(1.7 MB)



Commerical Wheelchair Elevator Specifications:

• Lifting height4’-14’ (53”, 77”, 101”, 125”, 149”, 171”)
• Rated load750lbs (340 kg)
• DriveBelt driven ball screw / 90 VDC ½ hp motor with brake
• Power supply115 VAC – 20 Amp grounded circuit
• Control circuit24 VAC
• Platform36” x 54” (straight-through) with 42” high guard panels and grab rail Stationary ramp
• Footprint49” x 54”
• Speed10 fpm
• ControlsConstant pressure paddle switch with emergency stop
• Manual loweringDevice provided
• Safety Design StandardsASME A18.1, Section 2 – Vertical Platform Lifts
• Safety Design StandardsCSA B44.1 / ASME 17.5 – Elevator and Escalator Electrical Equipment
• Safety FeaturesSafety pan, Final limit, Ball nut safety backup, Non-skid surface, Tower Braces (CPL800 and higher)
• Warranty1-Year parts
